Suspension Air Spring W01-358-7564 Firestone 1B8-550 Goodyear Rubber Air Bag

Name: Suspension Air Spring W013587564 Firestone 1B8550 Goodyear Rubber Air Bag
Brand: GUOMAT
Price: 1 USD

China Suspension Air Spring W01-358-7564 Firestone 1B8-550 Goodyear Rubber Air Bag wholesale

Brand Name : GUOMAT

Model Number : 1B8X4

Certification : ISO/TS16949, ISO9001

Place of Origin : Guangdong, China

MOQ : 5

Price : Negotiable

Payment Terms : L/C, D/A, D/P, Western Union

Supply Ability : 1000PCS/Week

Delivery Time : 5-8 Working Days

Packaging Details : Strong Carton Box or as Customers Requirement

Model NO. : 1B8X4

Structure : Double Convoluted

Damping Force Direction : Bidirectional

Function : Reduce Shock

Quality : 100% Tested

Trademark : GUOMAT

After-sales Service : 1 Year

Type : Gas-Filled

Contact Now

Suspension Air Spring W01-358-7564 Firestone 1B8-550 Goodyear Rubber Air Bag

Product Information

Cover Plate

Top Cover Plate Diameter: 5.31 in.
Screw Center Distance of Top Cover Plate: 2.75 in.
Bottom Cover Plate Diameter: 5.31 in.
Screw Center Distance of Bottom Cover Plate: 2.75 in.

Nut/Blind Nut

Top Cover Plate Screw(Nut) Tooth: 3/8-16 blind nuts
Bottom Cover Plate Screw(Nut) Tooth: 3/8-16 blind nuts

Gas Hole/Air Inlet/Air Fitting

Gas Hole: 1/4 NPT

Rubber Bellow

Rubber Bellow Max Dia: 9.1 in.
Minimum Height: 2 in.
Maximum Height: 6 in.

Style 116 Two Ply Bellows	Description	Assembly Order No.
	Blind nuts, 1/4 NPT	W01-358-7564, W01 358 7564, W013587564 WO1-358-7564, WO1 358 7564, WO13587564
	Blind nuts, 3/4 NPT	W01-358-7561, W01 358 7561, W013587561 WO1-358-7561, WO1 358 7561, WO13587561
	Countersunk steel bead rings, 13/4 bolts, nuts, washers	W01-358-7568, W01 358 7568, W013587568 WO1-358-7568, WO1 358 7568, WO13587568
	Blind nuts with installed 1/4 NPT	W01-A72-7518, W01 358 7518, W013587518 WO1-358-7518, WO1 358 7518, WO13587518
	Rubber bellows only	W01-358-0133, W01 358 0133, W013580133 WO1-358-0133, WO1 358 0133, WO13580133
Style 117 High Strength Bellows	Blind nuts, 1/4 NPT	W01-358-7600, W01 358 7600, W013587600 WO1-358-7600, WO1 358 7600, WO1357600
	Blind nuts, 3/4 NPT	W01-358-7602, W01 358 7602, W013587602 WO1-358-7602, WO1 358 7602, WO1357602
	Countersunk steel bead rings, 13/4 bolts, nuts, washers	W01-358-7606, W01 358 7606, W013587606 WO1-358-7606, WO1 358 7606, WO1357606

Applications

Pulp and paper industry
Lumber mills
Lift tables
Tooling and machining system
Energy production
Tooling robotics and automation
Component assembly
Automotive assembly
Medical equipment
Conveyor systems
Packaging
