| Type | Truck Air Spring,Rolling Lobe Air Spring |
| Material | Rubber,Steel |
| Warranty | 12 Months |
| Brand | GUOMAT |
| Quality | High-Quality |
| MOQ | 1 Piece |
Cross Reference Number
Firestone Number W01-M58-6366 / WO1-M58-6366
Firestone Number W01 M58 6366 / WO1 M58 6366
Firestone Number W01M586366 / WO1M586366
Firestone Number W01-M58-0919 / WO1-M58-0919
Firestone Number W01 M58 0919 / WO1 M58 0919
Firestone Number W01M580919 / WO1M580919
Contitech Number 4004 NP 03 / 4004NP03
Goodyear Number 1R11-706 / 1R 11-706 / 1R11706
Goodyear Number 1R11-750 / 1R 11-750 / 1R11750
Phoenix Number 1DK22E-5
Phoenix Number 1DK22E-8
Taurus Number K505-27SM
Dunlop FR Number D12B25 / D11B34 / D11B13
CF Gomma Number 1T300-33
CF Gomma Number 1T300-37
Airtech Number 130282
Airtech Number 132782
Airtech Number 34004KPP
WABCO Number 9518117500 / 951 811 750 0
WABCO Number 9518117130 / 951 811 713 0
SAF Number 3229000700 / 3 229 0007 00
SAF Number 2229000701 / 2 229 0007 01
SAF Number 3229000702 / 3 229 0007 02
SAF Type Number 2618
GUOMAT 1T6366 Air Spring Assembly Technical Parameters
| Top cover plate diameter | 262mm |
| Air inlet | M22X1.5 |
| Bolt/Stud | M12X1.75 |
| Center distance between two bolts | 158mm |
| Center distance between air hole and bolt | 73mm |
| Base width | 241mm |
| Base height | 141mm |
| The rubber bellows natural outer diamter | 300mm |
| Max.height | 540mm |
| Min.height | 185mm |
Please Note
- These air suspension airbags are aftermarket products. They will replace the original air spring airbags.
- Please check the pictures and drawings carefully before purchasing to ensure you are getting the correct air spring.
- Instructions are not included. Professional installation is recommended.
- Please feel free to contact us if there is anything we can do to help.
