Goodyear 1B9-202 Single Air Spring Rubber Bellows Style For Instrument

Product Categories

GUANGZHOU GUOMAT AIR SPRING CO. , LTD

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Goodyear 1B9-202 Single Air Spring Rubber Bellows Style For Instrument

Name: Goodyear 1B9202 Single Air Spring Rubber Bellows Style For Instrument
Brand: GUOMAT
Price: 49.9 USD

China Goodyear 1B9-202 Single Air Spring Rubber Bellows Style For Instrument wholesale

Brand Name : GUOMAT

Model Number : 1B9-202

Certification : ISO/TS16949:2009

Place of Origin : GuangDong, China

MOQ : 6PCS

Price : $49.9-59.9/pc

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1000pcs/week

Delivery Time : 2-8 work days

Packaging Details : Strong Carton Box Or As Customers Need

Warranty : 1 Year

Material : Rubber + Steel

Plate Diameter : 160mm

Packing : Brown Carton

Condition : 100% Brand-new

Operation : Gas-filled

Gas Hole : 1/4 NPTF

Type : Suspension Air Spring

Contact Now

Goodyear 1B9-202 Single Air Spring Rubber Bellows Style For Instrument

Product Details

Item	Air Spring/Shock Absorber Spring/Air Bellows
Brand	Guomat/Neutral
Model Number	1B9-202
Material	Rubber And Steel
Warranty	1 Year
MOQ	1 PCS If We Have Stock
Package	(1) Bubble Bag And Brown Carton (2) Customer Require Packaging (3) Normal Exported Package
Delivery Time	2-8 Working Days
Payment	T/T, L/C, PayPal, Western Union
After Service	(1) Examination Before Shipment (2) Follow Up The Customers' Feedback
Main products we sell	Air Spring,Convoluted Air Spring,Industrial Air Springs,Air Suspension Spring,Air Compressor,Air Valve,Bus Rubber Bellows,Truck & Trailer Air Bags,Cabin Air Shock,Electric Water Pump

Cross Information

Goodyear 1B9-202

Technical Data

Deflection(Height min):60mm

Deflection(Height max):160mm

Working stroke:100mm

Measurement d max:240mm

Top Cover Plate Diameter:160mm
Bottom Cover Plate Diameter:160mm
Air Inlet:1/4 NPTF
Screw Center Distance Of Top Cover Plate:89mm
Screw Center Distance Of Bottom Cover Plate:89mm
Screw And Gas Hole Distance Of Top Cover Plate:44.5mm
Top Cover Plate Screw (Nut) Tooth:2X3/8-16UNC
Bottom Cover Plate Screw (Nut) Tooth:2X3/8-16UNC
Rubber Bellow MAX Diameter:240mm
The Working Stroke:128mm

Hot Selling Air Spring

FOR SCANIA TRUCK
FOR VOL-VO TRUCK
FOR DAF TRUCK
FOR BPW TRUCK
FOR HENDRICKSON TRUCK
FOR SAF TRUCK
FOR FREIGHTLINER TRUCK
FOR MERCEDES-BNEZ TRUCK
FOR MAN TRUCK
FOR MERITOR TRUCK

Air Spring Introduction

Air springs have been used in heavy duty vehicle suspension systems for nearly a century, where they have been able to provide usefulness by taking advantage of the compressed air required for vehicle braking systems. Air springs have provided a two-fold advantage over mechanical leaf- or coil-springs. One advantage with air suspension is the extra comfort provided by being able to vary the air pressure inside the spring, which changes the spring rate, and therefore, ride quality. Additionally, because variable control over air pressure adjusts the deck or trailer height, aligning loading docks to the level of the deck is possible when dock plates are unavailable.
