2B9-253 Industrial Air Spring Actuators Airide Air Spring Double Convoluted For Machines
GUOMAT NO. 2B9253 Specifications:
Roof hole/stud: 3 pieces
Bottom hole / stud: 2 pieces
Top cover: 6.4 inches / 160 mm
Bottom cover diameter: 6.4 inches / 160 mm
Folding height: 3.8 inches / 96 mm
Top cover screw center distance: 3.5 inches / 89 mm
Screw center distance of bottom cover: 3.5 inches / 89 mm
Rubber bellows natural diameter: 232.5 mm
Working stroke: MAX 309 mm to MIN 96 mm / MAX 12.2 inches to MIN 3.8 inches
Maximum height: 12.2 inches / 309 mm
Minimum height: 3.8 inches / 96 mm
Compressed height: 8.3 inches / 213 mm
Rubber bellows natural: 9.2 inches / 235 mm
GUOMAT NO. 2B9253 Cross others OEM
| OEM References Numbers | References Numbers |
| Firestone W01-358-6951 | Triangle : 6332/4427 |
| Contitech FD 200-25 | Leland : Sc2125 |
| Goodyear 578923206 | Watson&Chalin : AS0119F |
| Goodyear 2B9-253 | : AS01451G |
| | Ridewell : 1003586945C |
Goodyear Trimmed: 2B9253
Conti Tech: FD200-25427 / FD 200-25 427
Firestone W01-358-6945 / 20-2
Goodyear 2B9-253
Goodyear Flexmember: 578-92-3-206 / 578923206 / 578 92 3 206
Triangle Spring: 4427 / 6332
Firestone: 6945
Conti Tech: 64550
Ridewell: 1003586945C
Batco: 10-96945
UCF / Impex: AB-2B9-253
T.W. Distribution: AB6945
Dallas Spring: AS6945
Midland / Haldex: CS209253
Euclid/Meritor Aftermarket: E-FS6945
Euclid/Meritor Aftermarket: FS6945
Leland: SC2125
Watson&Chalin : AS0119F / AS01451G
Details Technical data at the below photo
Vibration isolation - dynamic characteristic values
Pneumatic application - static characteristic values Force F [kN]
