Super Cushion Goodyear Air Spring 2B9-204 Firestone W013586900 For Suspensions 630173

Name: Super Cushion Goodyear Air Spring 2B9204 Firestone W013586900 For Suspensions 630173
Brand: GUOMAT
Price: 1 USD

China Super Cushion Goodyear Air Spring 2B9-204 Firestone W013586900 For Suspensions 630173 wholesale

Brand Name : GUOMAT

Model Number : 2B6900

Certification : ISO/TS16949:2009

Place of Origin : China

MOQ : 1pc

Payment Terms : T/T, Western Union,Paypal or Others

Supply Ability : 1000pcs/week

Delivery Time : 2-8 work days

Packaging Details : strong carton box or as customers need

Material : Rubber and Iron/Steel

Firestone Part Number : W01-358-6900

Warranty : 12 Months

Weight : 3.5 kg

Other Name : Air Bags For Pneumatics

Pressure Ability : 0.2-0.8 M Pa

GUOMAT : 2B6900

Gas Hole / Air inlet : 3/4 NPT

Contact Now

Goodyear Super Cushion Air Spring 2B9-204 Firestone W013586900 For Suspensions 630173

Specifications and Technical Data of 2B6900

Firestone Part Number:W01-358-6900 / W013586900 / W01 358 6900

Compressed Height: 3.12

Top Plate Number:3079

Top Cover Plate Diameter: 6.31 inches / 160mm

Bottom Cover Plate Diameter: 6.31 inches / 160mm

Screw Center Distance : 89 mm

Distance Gas Hole Between Nut 38 mm

Top Cover Plate Screw (Nut) Tooth : 2pcsX 3/8-16UNC

Bottom Cover Plate Screw (Nut) Tooth : 2pcsX 3/8-16UNC

Rubber Bellows MAX Diameter: 251 mm

Rubber Bellows Natural Diameter 224 mm

The Working Stroke : MAX 260 mm to MIN 75 mm

Gas Hole / Air inlet : 3/4 NPT

Firestone Bellows Number:20

Goodyear Part Number:2B9-204 / 2B9204 / 2B9 204

Goodyear Bellows Number:578-92-3-202 / 578923202 / 578 92 3 202

GUOMAT NO. 2B6900 OEM Original Equipment Manufacturer:

Reference	OEM
Firestone	W01-358-6900
Contitech	FD 200-19 319
Contitech	161017
Goodyear	2B8-157
Goodyear	2B9-204
Goodyear	2B9-207
Goodyear	2B9-216
Goodyear	578923202
Dina	A1812719
MASA	227138412
Ridewell	1003586900C
Suspensions	630173
Watson&Chalin	AS-0156G

Super Cushion Goodyear Air Spring 2B9-204 Firestone W013586900 For Suspensions 630173
