FIRESTONE W01-358-8050 TRUCK AIR BAG FOR HENDRICKSON S4771 - AUTOMANN 1D28K-8050
Product Information
GUOMAT NO. : 1T8050
VEHICLE TYPE: Truck
POSITION: The Floating Bridge
PISTON : With Piston
OEM REFERENCES
FIRESTONE 1T19J-6 / 1T19J 6 / 1T19J6
FIRESTONE W01-358-8050 / W01 358 8050 / W013588050
CONTITECH 1110.5C-16A320 / 1110.5C 16A320 / 1110.5C-16A 320
Conti Tech: 1110.5E-16A320 / 1110.5E 16A320 / 1110.5E-16A 320
GOODYEAR 1R14-039 / 1R14 039 / 1R14039
Goodyear Airspg: 1R14-083
VIBROCOUSTIC V1DK28A-8050
VEHICLE OEM REFERENCES
DAYTON 352-8050
HENDRICKSON S4771
HENDRICKSON B-4771
Hendrickson: 36514-13
LOADGUARD C2052
WESTAR PART 87-78050
EUCLID PART E-FS8050
AUTOMANN PART 1D28K-8050
448050-C NAVISTAR 1685174C1
Triangle Spring: 8320
Neway 57008050
Batco 10-98050
Navistar/IHC 1685174C1
Automann AB1DK28A-8050
UCF/Impex AB-1R14-039
T.W. Distribution AB8050
Watson & Chalin AS0039
Dallas Spring AS8050
Sirco AS-8050
Midland/Haldex CS114039
Euclid/Meritor Aftermarket E-FS8050
Euclid/Meritor Aftermarket FS8050
Flagg HT228
BWP M-3510
Leland SC2052
Technical Parameters
Weight: 11.0kg
Deflection (Hight min) : 145mm
Deflection (Hight max) : 450mm
Working stroke : 305mm
Loading cap. at 5 bar : 3.5KN
Loading cap. at 7 bar : 4.5KN
Top Plate Hole/Stud: 2
Bottom Plate Hole/Stud: 4
Top Plate Diameter: 11.3
Bottom Plate Diameter: 11.8
Collapsed Height: 5.7
Flexmember: 566-28-3-015
Piston: 566-20-7-076
Piston Type: A
ABOUT US...
Guangzhou Guomat Air Spring CO., Ltd.is located in Guangzhou, about 15min’s drive from BAIYUN AIRPORT. Our mainly products air spring, rubber bellow, air suspension compressor and refitted suspension system. They are widely used in bus, truck, cabin, vehicles’ seat, luxurious car and industrial machine field.
Our goal is to make your choice easier and save your money. We serve customers world-wide by offering quality goods at unbeatable prices, all while maintaining a focus on superior customer service. PLEASE FEEL FREE TO ASKANY QUESTIONS. All questions will be answered promptly (usually in less than 24 hours except weekends and holidays)
Give us your trust and we'll help you to repair or update your car!
The warranty period of Air Spring
GUOMAT air spring made of high quality materials(natural rubber), the warranty period of One Year.
Our air spring provides high performance and dynamics while ensuring perfect grip and maximum driving comfort in any case. In addition to improving the stability of the vehicle, they can reduce the number of vibratory movements due to road defects to optimize the comfort of passengers and allow you to ride smoothly.
Our dampers are designed to provide excellent ride quality by quickly adjusting to different road and vehicle conditions while providing ultimate safety and functionality.
